| Engine: | Single cylinder, four stroke, air cooling | Wheel Tire: | 4.8-8 16″ DOT |
| Displacement: | 420cc | Cutting method: | Disc |
| Chipping capacity: | 120mm | Diameter: | 550mm |
| Weight: | 238kgs | Thickness: | 20mm |
| Length: | 2270mm | Bearing: | UCF207 |
| Width: | 1000mm | Cutter wheel RPM: | 1600 rpm/min |
| Height: | 1655mm | Blade Nos.: | 2 x fly knives, 1 fixed knife |
| Operating RPM: | 3600rpm | Drive: | Direct Belt Drive / B-725Li / Centrifugal Clutch |
| Type of Fuel: | Petrol | Package Size: | 115*80*100cm |
| Starting method: | Recoil/Electric(optional) | Gross Weight: | 258kgs |
| Oil sensor: | Yes | 40HQ Loading Qty.: | 66 sets |
