| Model | HBWS15 | HBWS18 | HBWS25 | HBWS30 | HBWS35 | HBWS40 |
| Split Force: | 15Ton | 18Ton | 25Ton | 30Ton | 35Ton | 40Ton |
| Log Capacity: | 625mm | 630mm | 630mm | 630mm | 630mm | 630mm |
| Control valve: | Auto Return with Ajustable Detent | Auto Return with Ajustable Detent | Auto Return with Ajustable Detent | Auto Return with Ajustable Detent | Auto Return with Ajustable Detent | Auto Return with Ajustable Detent |
| Pump Size: | 14 GPM | 14 GPM | 14 GPM | 14 GPM | 17 GPM | 17 GPM |
| Cylinder inner diameter: | 3 inch | 3.5 inch | 4 inch | 4.5 inch | 5 inch | 5 inch |
| Hydraulic Rod Diameter: | 40mm | 44.5mm | 44.5mm | 44.5mm | 50.8mm | 50.8mm |
| Hydraulic Cylinder Stroke: | 602mm | 602mm | 602mm | 602mm | 602mm | 602mm |
| Cylinder Cycle Time: | 7.6S | 9.1S | 10.9S | 14.3S | 13.8S | 13.8S |
| Hydraulic Capacity (L): | 15L | 19L | 23L | 24.5L | 27L | 27L |
| Fuel Capacity (L): | 12.5L | 15L | 17L | 18L | 22L | 22L |
| Whether the hydraulic oil is pre filled: | Not Included | Not Included | Not Included | Not Included | Not Included | Not Included |
| Size of cleaver: | 180mm | 180mm | 200mm | 200mm | 200mm | 200mm |
| Tire: | 4.80-8 | 4.80-8 | 4.80-8 | 4.80-8 | 4.80-8 | 4.80-8 |
| Engine: | 6.5HP | 6.5HP | 7HP | 7HP | 9HP | 15HP |
| Overall dimensions: | 1797×735×995 | 2446×1166×994 | 2221×1186×1002 | 2221×1246×1002 | 2221×1326×1002 | 2221×1326×1002 |
| Net weight: | 131kg | 208kg | 221kg | 228kg | 247kg | 249kg |
