| Model | DL50DU-2WD-1.6 | |
| Motor Type | Permanent magnet synchronous motor | |
| Rated Power and Rev | 5 KW/3000 rpm | |
| Max. Power and Rev | 11 KW/6000 rpm | |
| Max. Torque and Rev | 70 N.m/6000 (r/min) | |
| Battery | Lithium , 72V83Ah | |
| Charging Voltage | 220 V | |
| Charging Time | 5 hour | |
| Endurance Time | 1.8 hour (25 km/h, no load) | |
| Range | 45 km (25 km/h, unloaded) | |
| Max. Speed | 30 km/h | |
| Gradeability | ≤20° | |
| Transmission | Shaft | |
| Brake Method/Type | Front: hand/drum , Rear: foot/drum | |
| Tire | Tubeless Tire, Front: 22*8-10 , Rear: 22*10-10 | |
| Wheelbase | 1950±50 mm | |
| Min. Ground Clearance | 170 mm ± 10 mm | |
| Rated Load Weight | 500 kgs | |
| L×W×H (Cargo) | 1600×1200×500(±50) mm | |
| L×W×H (Farm ATV) | 3100×1200×1400(±50) mm | |
| Container Loading Quantity | 20GP: 8pcs , 40HQ: 22pcs | |
