| Model | DL40DU | |
| Motor Type | Permanent magnet synchronous motor | |
| Rated Power and Rev | 4 KW/4000 rpm | |
| Max. Power and Rev | 8 KW/5700 rpm | |
| Max. Torque and Rev | 70 N.m/900 (r/min) | |
| Battery | Lithium , 76.8V96Ah | |
| Charging Voltage | 220 V | |
| Charging Time | 5.5 hour | |
| Endurance Time | 3 hour (25 km/h, no load) | |
| Range | 75 km (25 km/h, unloaded) | |
| Max. Speed | 43 km/h | |
| Gradeability | ≤20° | |
| Transmission | Shaft | |
| Brake Method/Type | Front: hand/Disc , Rear:foot/ Disc | |
| Tire | Tubeless Tire, Front: 24*8-12 , Rear: 24*10-12 | |
| Wheelbase | 1980±20 mm | |
| Min. Ground Clearance | 200 mm ± 10 mm | |
| Rated Load Weight | 500 kgs | |
| L×W×H (Cargo) | 1600×1200×485 (±50) mm | |
| L×W×H (Farm ATV) | 3130×1270×1470(±30) mm | |
| Container Loading Quantity | 20GP: 6pcs , 40HQ: 20pcs | |
