| Model | DL40DAU-A | |
| Motor Type | Permanent magnet synchronous motor | |
| Rated Power and Rev | 4 KW/4000 rpm | |
| Max. Power and Rev | 8 KW/5700 rpm | |
| Max. Torque and Rev | 70 N.m/900 (r/min) | |
| Battery | Lithium , 76.8V60Ah | |
| Full Charging | 3 hour (220V) | |
| Range | 50-60 km | |
| Max. Speed | 43 km/h | |
| Gradeability | ≥25° | |
| Transmission | Shaft , Rear-wheel drive | |
| Brake Method/Type | Front: hand/Disc , Rear:foot/ Disc | |
| Tire | Tubeless Tire, Front: 24*8-12 , Rear: 24*10-12 | |
| Wheelbase | 1170mm | |
| Min. Ground Clearance | 200 mm ± 10 mm | |
| L×W×H | 1980×1060×1200 mm | |
| Container Loading Quantity | 20GP: 10pcs , 40HQ: 30pcs | |
