Product details
| Model | DL250AU | |
| Engine | GY6-250 | |
| Engine Type | Single cylinder, 4-stroke | |
| Displacement | 229.2 cc | |
| Bore × Stroke | 67×65 mm | |
| Compression Ratio | 10.0: 1 | |
| Max. Power and Rev | 12 kW (6500r/min) | |
| Max. Torque and Rev | 17.5 N·m (5500r/min) | |
| Max.Speed | 60 km/h | |
| Gradeability | ≤15° | |
| Starting Method | Electric start | |
| Gear Shaft Mode | CVT , D-N-R | |
| Transmission | Shaft , Rear-wheel drive | |
| Brake Type | Front: Drum , Rear: Drum | |
| Tire | Tubeless Tire, Front: 22*8-10 , Rear: 22*10-10 | |
| Wheelbase | 1150±30 mm | |
| Min. Ground Clearance | 170 mm ± 10 mm | |
| Fuel Tank Capacity | 11.8 L | |
| L×W×H | (1950×1180×1330) ±30 mm | |
| Container Loading Quantity | 20GP: 10pcs , 40HQ: 33pcs | |
