12 Rows Seeding Fertilizing Machine

Product Description

The Seeding Fertilizing Machine is perfectly suited for spreading all common types of small seeds, seed mixtures, and fertilizer. Support customization of your needs according to farmland conditions.



It offers a combined one 12 rows 300L pneumatic seeder, one 8 rows pneumatic fertilizer box, Rotary Tiller, Fertilizer Drill Sowing assembly, Disc Furrow Opener, and farmland Roller. This allows farmers to utilise the optimal time for sowing and benefit from immediate erosion protection.



The use radar speed measurement and centrol control system to accurately control the sowing and fertilizing amount. The pneumatic seeder with Intelligent tablet APP, central control system and radar sensor ensures seeds precise distribution to the farmland even in the windy condition. Using the electrically controlled metering shaft, the seed enters the air channel where it is conveyed by the blower fan to the ends through plastic hoses.



The fertilizer box is controlled by App application with radar senor to set the accurate fertilizer amount and save your material. The drill sowing ensures that the fertilizer can arrived at the soil linely even in windy condition.


A large selection of seed hopper sizes, seed roller and seed rows allow us to offer you a customized solution for every need and budget, and to save seeds and fertilizer volume and labor cost.



Seeding Fertilizing Machine Assembly
Seed Rows1-12 Outlets
Fertilizer Rows1-8 Outlets
Smart Tablet with YongXiang APP10 inches
Seeder Hopper100/300/600L
Fertilizer Hopper75/150/350L
Radar SensorYes
Seed Roller

12 Rows: Rice, Wheat, Soybean

Sorghum, Green Corn, Fertilizer, Grass seed. etc

Fertilizer Roller8 Rows: Ferlizer
Rotary Tiller2/2.3/2.5m Optional
Disc Furrow Opener12 pcs
Land Roller2/2.3/2.5m, Iron/Stainless Steel Optional
PloughYes
Battery CableYes

Hydraulic Folding Oil Cylinder

Optional
Disc Furrow Depth Adjustment(10cm)

Hand Cranked Lift Jack(0-100)

or Simple 7 level Lift Device

Seed Electric ScaleYes
Seed Weight Calibration BagYes





Specification
Working Width2m2.3m2.5m
Horse Power58.82-66.18 KW73.5-95.6 KW88.2-110.3 KW
Structural Type:3-Point Suspension3-Point Suspension3-Point Suspension
Size:

2350*2200*1900mm

2350*2546*1900mm

2350*2745*1900mm

Working Area/Hour0.4-1.2 hm²/H

0.46-1.35 hm²/H

0.5-1.5 hm²/H

Cultivation Deepth8-16 cm8-16 cm12-18 cm
Seed Row Spacing Adjustable15-30 cm15-30 cm15-30 cm
