ZK-360 Skid Steer Loader

ZK-360 Skid Steer Loader2
ZK-360 Skid Steer Loader1
ZK-360 Skid Steer Loader3
ZK-360 Skid Steer Loader4
ZK-360 Skid Steer Loader
ZK-360 Skid Steer Loader2
ZK-360 Skid Steer Loader1
ZK-360 Skid Steer Loader3
ZK-360 Skid Steer Loader4
ZK-360 Skid Steer Loader

ZK-360 Skid Steer Loader

Inquire Now
Add To Cart

Product Description

ModelZK-360
EngineKoop/Briggs & Stratton
Rated power10/13.5HP
Calibration speed3000rpm
CylinderSingle
Intake methodNatural
Displacement420cc
Emission StandardEuro 5/EPA
Rated load200kg
Max. load300kg
Max. rising force350KN
Bucket volume0.12m³
Walking speed0-6km/h
Working system pressure17-21bar
Fuel tank volume5L
Operating weight900kg
Tire15*72
Max. operating height2450mm
To bucket pin height1870mm
Overall height1300mm
Bucket horizontal maximum height1810mm
Total length without accessories1450mm
Overall length with standard bucket2100mm
Max. height unloading angle34°
Unloading height1510mm
Unloading distance450mm
The flip angle of the bucket on the ground27°
Bucket flip angle at highest114°
wheelbase850mm
Ground clearance150mm
Tail length280mm
Wheel base (standard tires)720mm
Total width (standard tires)880mm
Bucket width1000mm
